Description

LED driver that supports 4 channels 350 mA each.

Driver PX241 is designed to control LEDs. Built-in receiver allows to control up to 4 channels (R, G, B, W) directly from the DMX-512 protocol. Wide range of supply voltage and high current capacity outputs allow to activate large quantities of diodes. PX241 can be controlled by DMX or work independently. In this case, the user has at his disposal a fully programmable scene and 19 pre-programmed sequences, which playback speed and steps smoothness can be modified according to the users' needs.

Driver has a built-in tuning frequency signal (process "flicker free"), which makes it particularly useful in applications for the television industry. Because the RGB series LEDs often differ quite substantially in parameters between each other, this can cause problems in obtaining a white color. That is why PX241 features a handy feature called - white balance. Thanks to it you can adjust the control of individual colors by the driver to achieve the full gain settings of the color white. What's more, this feature allows a certain extent, correct the color temperature of white color.
CAUTION!
THE DEVICE IS OUT OF PRODUCTION! It has been replaced with PX782 module.
