Description
The PxDuo 2x3 12V LED lamp has been designed to illuminate interiors and exterior architectural details.
The lamp uses six high-efficiency LEDs by OSRAM Oslon in the following system: 3 LEDs directed downwards and 3 directed upwards.
CAUTION!
THE DEVICE IS OUT OF PRODUCTION!
Technical data
| number of LEDs | 6 (3 up and 3 down) |
| beam angle | 25° (typical), 10°, 40° (on order) |
| available LED colours | white warm, white cold, white neutral |
| brightness (for 25° lens at 1m distance) | 1120 lx (in one direction) |
| power supply | 12 V DC |
| current consumption | 700mA |
| weight | 1,6 kg |
| dimensions | outer diameter of the light tube: 60 mm
total height of the lamp: 237 mm
overall width of the lamp: 134 mm |
