Description

CAUTION!
The device has been withdrawn from production and replaced with a new module PX783 Driver LED C.C. 4x700mA.
LED driver supports 4 channels of 700 mA each.

Driver PX211 is designed to control LEDs. Built-in receiver allows to control up to 4 channels (R, G, B, W) directly from the DMX protocol. Wide range of supply voltage and high current capacity outputs allow to activate large quantities of diodes. PX211 can be controlled by DMX or work independently. In this case, the user has at his disposal a fully programmable scene and 19 pre-programmed sequences, which can on its own can change the playback speed and steps smoothness.

Driver has a built-in tuning frequency signal (process "flicker free"), which makes it particularly useful in applications for the television industry. Because the RGB series LEDs often differ quite substantially in parameters between each other, this can cause problems in obtaining a white color. That is why PX211 features a handy feature called - white balance. Thanks to it you can just adjust the control of individual colors by the driver to achieve the full gain settings of the color white. What's more, this feature allows a certain extent, correct the color temperature of white color.
